Easy UPS On-Line
High quality, Double-conversion On-line UPS designed for essential power protection needs even in the most unstable power conditions
For small to medium businesses, APC by Schneider Electric delivers a new category of UPSs designed for essential power protection needs even in the most unstable power conditions. APC Easy UPS 1 Ph Online is a versatile, high quality, cost competitive UPS developed to handle a wide voltage range, inconsistent power conditions and delivering the quality millions of IT professionals trust around the world.
- General Information
- Manufacturer
- Schneider Electric SA
- Manufacturer Website Address
- http://www.schneider-electric.com
- Brand Name
- APC by Schneider Electric
- Product Line
- Easy UPS
- Product Series
- SRV
- Product Type
- Double Conversion Online UPS
- Technical Information
- Plug/Connector Type
- Hard Wire 3-wire
- Receptacle Type
- Terminal Block
- Transfer Time
- 0 ns
- Phase
- Single Phase
- Application/Usage
- Business
- Workstation
- Server
- Industrial Equipment
- Desktop Computer
- Communication System
- Power Description
- Load Capacity (VA)
- 6 kVA
- Load Capacity (Watt)
- 6 kW
- Input Voltage
- 230 V AC
- Output Voltage
- 220 V AC
- 230 V AC
- 240 V AC
- Input Frequency
- 70 Hz
- Output Frequency
- 60 Hz
- Waveform Type
- Sine Wave
- Surge Energy Rating
- 600 J
- Management
- Alarm
- Battery Level
- Battery Mode
- Bypass Mode
- Fault
- Controls/Indicators
- Status Indicators
Multifunction LCD
- Interfaces/Ports
- Serial Port
- Yes
- EPO Port
- Yes
- USB (HID Compliant) Port
- Yes
- Battery Information
- Battery Characteristics
- Maintenance-free, Sealed
- Battery Chemistry
- Lead Acid
- Typical Battery Recharge Time
- 3 Hour
- Replaceable Battery
- Yes
- Environmental Conditions
- Maximum Operating Temperature
- 40°C
- Maximum Operating Elevation
- 3 km
- Maximum Storage Elevation
- 14.76 km
- Operating Humidity
- 0% - 95%
- Storage Relative Humidity
- 0% - 95%
- Physical Characteristics
- Height
- 173 mm
- Width
- 438 mm
- Depth
- 710 mm
- Rack Height
- 2U
- Form Factor
- Rack-mountable
- Weight (Approximate)
- 61 kg
- Miscellaneous
- Environmentally Friendly
- Yes
