- General Information
- Manufacturer
- Schneider Electric SA
- Manufacturer Website Address
- http://www.schneider-electric.com
- Brand Name
- APC by Schneider Electric
- Product Line
- NetShelter
- Packaged Quantity
- 1 / Pack
- Product Type
- PDU
- Warranty
- Parts Warranty/Labor
- 2 Year
- Technical Information
- PDU Type
- Basic
- Plug/Connector Type
- IEC 60320 C20
- Plug/Connector Detail
- 1 x IEC 60320 C20
- Receptacle Type
- IEC 60320 C13
- IEC 60320 C19
- Receptacle Detail
- 10 x IEC 60320 C13
- 2 x IEC 60320 C19
- Load Capacity (VA)
- 3.68 kW
- Power Description
- Input Voltage
- 120 V
- 208 V
- 230 V
- Input Voltage Range
- 90 V AC - 250 V AC
- Output Voltage
- 120 V AC
- 208 V AC
- 230 V AC
- Input Current
- 16 A
- Input Frequency
- 60 Hz
- Physical Characteristics
- Color Family
- Black
- Product Color
- Black
- Mounting Orientation
- Horizontal
- Mount Type
- Rack-mountable
- Rack Height
- 1U
- Cord Length
- 2.50 m
- Height
- 44 mm
- Width
- 447 mm
- Depth
- 57 mm
- Weight (Approximate)
- 979.8 g
- Environmental Conditions
- Minimum Operating Temperature
- 0°C
- Maximum Operating Temperature
- 45°C
- Minimum Operating Humidity
- 0%
- Maximum Operating Humidity
- 95%
- Minimum Storage Temperature
- -25°C
- Maximum Storage Temperature
- 65°C
- Miscellaneous
- Additional Information
- Maximum Line Current per phase: 16 A
- Always on Outlets: 12
- Green Premium
- Yes
- Optimized Energy Efficiency
- Yes
- REACH free of SVHC
- No
- Lead Free
- Yes
- REACH Declaration URL
- https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=exportPdfReach&pid=759556&lang=en-us
- EU RoHS Declaration URL
- https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=export&pid=759556&lang=en-us
- Environmental Profile Availability
- https://download.schneider-electric.com/files?p_enDocType=Environmental+Disclosure&p_Doc_Ref=ENVPEP1512009_EN
- End of Life Manual Availability
- https://download.schneider-electric.com/files?p_enDocType=Circularity+Profile&p_Doc_Ref=ENVEOLI1512009_EN
- California Proposition 65 Warning
- WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov
- WEEE Statement
- The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
