The CE100 USB KVM Extender with superior video quality and built-in ESD protection allows access to a computer system from a remote USB console (USB keyboard, USB mouse, and monitor).
The CE100 improves on previous designs by: 1) incorporating a compensation adjustment function at the Remote unit for greater video quality; and 2) using inexpensive Cat 5e cable, instead of bulky, expensive, standard cables, to provide a neater, more convenient, more reliable data transfer connection.
- General Information
- Manufacturer
- ATEN Technology, Inc
- Manufacturer Website Address
- http://www.aten.com
- Brand Name
- ATEN
- Product Line
- ProXime
- Product Type
- KVM Console/Extender
- Warranty
- Limited Warranty
- 2 Year
- Technical Information
- Connectivity Technology
- Wired
- Number of Computers Supported
- 1
- Number of Remote Users Supported
- 1
- Maximum Operating Distance
- 100 m
- Video
- Graphic Mode
- WUXGA
- Maximum Video Resolution
- 1920 x 1200
- Interfaces/Ports
- Network (RJ-45)
- Yes
- USB
- Yes
- VGA
- Yes
- Number of VGA Ports
- 2
- Number of Network (RJ-45) Ports
- 2
- Number of USB Ports
- 3
- Power Description
- Input Voltage
- 5 V DC
- Physical Characteristics
- Product Color
- Black
- Form Factor
- Wall Mountable
- Transmitter Height
- 24 mm
- Transmitter Width
- 57.40 mm
- Transmitter Depth
- 91 mm
- Receiver Height
- 24 mm
- Receiver Width
- 57.40 mm
- Receiver Depth
- 91 mm
- Transmitter Weight (Approximate)
- 160 g
- Receiver Weight (Approximate)
- 160 g
- Miscellaneous
- Package Contents
- 1 x CE100L Mini USB KVM Extender (Local Unit)
- 1 x CE100R Mini USB KVM Extender (Remote Unit)
- 1 x USB/VGA Cable
- 1 x Power Adapter (for Remote Unit)
- 1 x Mounting Kit
- 1 x User Instructions
- Environmentally Friendly
- Yes
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
- Waste Electrical and Electronic Equipment Directive (WEEE)
