- General Information
- Manufacturer
- Elo Touch Solutions, Inc
- Manufacturer Website Address
- http://www.elotouch.com
- Brand Name
- Elo
- Product Series
- 02
- Packaged Quantity
- 1
- Product Type
- LCD Touchscreen Monitor
The Elo 1002L Touchscreen Monitor is designed with the same seamless style that spans across the entire line up of 02-Series Monitors. With a compact form factor and clean design for easy integration, the 1002L offers the flexibility to install as a traditional POS terminal or a customer facing point of interaction - making it well-suited for point-of-sale, self-service, signage and hospitality applications. And with a variety of peripherals, the monitor can be transformed to meet the demands of almost any blueprint.
Single Cable Connection
The 1002L provides a USB Type-C interface that provides touch, video and power. By reducing the number of cables required for any set up from 3 to 1, installation and servicing is a breeze. In case your PC isn't equipped with USB Type-C yet, you can still use traditional HDMI or VGA to connect to your PC.
One for You.
One for Your Customers.
The 02-Series offers dual functionality. Use it as a traditional POS terminal or customer facing display - or BOTH! Start increasing brand loyalty and customer satisfaction by offering your customers a point of interaction to review transactions, participate in loyalty programs or see the latest promotion.
Well-Suited for...
Not all businesses have the same needs. Whether you need a touchscreen at the point of sale to process a transaction or in a restaurant to enable self-service for guests to view your menu and submit their order, the line of 02-Series monitors can support the installation needs with ease while maintaining a modern, sleek aesthetic.
- Technical Information
- Screen Size Class
- 10"
- Viewable Screen Size
- 25.7 cm (10.1")
- Screen Mode
- WXGA
- Screen Surface
- Anti-glare
- Panel Technology
- Thin Film Transistor (TFT)
- Response Time
- 29 ms
- Aspect Ratio
- 16:10
- Horizontal Viewing Angle
- 170°
- Vertical Viewing Angle
- 170°
- Mount Type
- Rear Mount
- Placement
- Tabletop
- Backlight Technology
- LED
- Features
- Anti-glare
- On-screen Display (OSD)
- Cable Lock Slot
- Horizontal Frequency
- 31.50 kHz to 80 kHz
- Vertical Frequency
- 60 Hz
- Curved Screen
- No
- Video
- Maximum Resolution
- 1280 x 800
- Standard Refresh Rate
- 60 Hz
- Colour Supported
- 262,000 Colors
- Native Contrast Ratio
- 800:1
- Brightness
- 350 cd/m²
- Maximum Refresh Rate
- 60 Hz
- Audio
- Speakers
- Yes
- Number of Speakers
- 2
- Speaker Output Power
- 4 W
- Touchscreen Information
- Touchscreen
- Yes
- Touchscreen Type
- TouchPro Projected Capacitive
- Multi-touch Screen
- Yes
- Number of Simultaneous Touchpoints
- 10
- Interfaces/Ports
- HDMI
- Yes
- USB
- Yes
- VGA
- Yes
- USB Type-C
- Yes
- Number of USB Ports
- 4
- Total Number of USB Type-C Ports
- 1
- Built-in Devices
- Built-in Devices
- USB Hub
- Power Description
- Input Voltage
- 12 V DC
- 120 V AC
- 230 V AC
- Operating Power Consumption
- 7.43 W
- Standby Power Consumption
- 1.26 W
- Off-Mode Power Consumption
- 200 mW
- Physical Characteristics
- VESA Mount Compatible
- Yes
- VESA Mount Standard
- 75 x 75
- Product Color
- Black
- Height
- 177.5 mm
- Width
- 254.8 mm
- Depth
- 29 mm
- Weight (Approximate)
- 884.5 g
- Miscellaneous
- Certifications & Standards
- Canada cUL, IC
- Europe CE
- Japan VCCI
- United States UL, FCC
- China CCC
- Korea, KCC, e-standby
- Australia RCM
- Mexico NOM
- Taiwan BSMI
- International CB
- RoHS
- China RoHS
- WEEE
- REACH
- India BIS
- Russia EAC
- Mean Time Between Failures (MTBF)
- 5.7 Year
- Environmentally Friendly
- Yes
