- General Information
- Manufacturer
- Hanwha Group
- Manufacturer Website Address
- http://www.hanwha.com
- Brand Name
- Hanwha
- Product Type
- Network Camera
Server-less solution with built-in rugged SSD
Conventional video surveillance systems require servers to record and manage cameras. SolidEDGE is a server-less solution equipped with a built-in rugged SSD that enables local storage of video footage and eliminating the need for external recording servers.
Up to 5 additional cameras recording and monitoring
Users can add up to five additional cameras to the single SolidEDGE camera.
Total of six cameras including SolidEDGE camera can record and monitor up to six video channels and therefore making it suitable for the SMB market such as coffee shops, restaurants and bakeries.
SolidEDGE includes 1ch Wisenet WAVE license so users only need to purchase a VMS license for each additional camera.
System scalability
SolidEDGE could be flexible and expandable for multi-site monitoring through Wisenet WAVE Sync. This feature enables remote access and management of on-premise security systems from anywhere in the world. Wisenet Wave Sync also keeps the system up-to-date with regular software and security updates.
- Technical Information
- Recording Formats
- Full HD
- HD Recording
- Yes
- Night Vision
- Yes
- Night Vision Distance
- 40 m
- Night Vision Type
- Infrared
- Display & Graphics
- Image Sensor Type
- CMOS
- Image Sensor Size
- 1/2"
- Colour Supported
- Colour
- Field of View
- H: 104°(Wide)~44°(Tele) V: 55°(Wide)~24°(Tele) D: 124°(Wide)~51°(Tele)
- Effective Camera Resolution
- 2 Megapixel
- Video
- Video Formats
- H.265
- H.264
- MJPEG
- H.265M
- H.265H
- H.264M
- H.264H
- Maximum Video Resolution
- 1920 x 1080
- Maximum Frame Rate
- 120 fps
- Analog Video Signal Format
- CVBS
- Lens
- Lens Type
- Varifocal
- Minimum Focal Length
- 4.38 mm
- Maximum Focal Length
- 9.33 mm
- Lens Included
- Yes
- Minimum Aperture
- f/2.15
- Maximum Aperture
- f/1.3
- Optical Zoom
- 2.1x
- Exposure
- Shortest Shutter Speed
- 1/12000 Second
- Longest Shutter Speed
- 1/5 Second
- Network & Communication
- Connectivity Technology
- Wired
- Ethernet Technology
- Gigabit Ethernet
- Protocols
- NTP
- HTTP
- HTTPS
- SSL/TLS
- DHCP
- FTP
- SMTP
- ICMP
- IGMP
- SNMPv1/v2c/v3 (MIB2)
- ARP
- DNS
- DDNS
- QoS
- UPnP
- Bonjour
- LLDP
- SRTP
- TCP
- UDP
- MQTT
- IPv6
- TCP/IP
- UDP/IP
- RTP/UDP
- RTP/TCP
- RTCP
- RTSP
- Remote Management
- Yes
- Storage
- Solid State Drive Capacity
- 1 TB
- Interfaces/Ports
- Network (RJ-45)
- Yes
- Power Description
- Input Voltage
- 12 V DC
- Power Source Type
- DC
- PoE+
- Physical Characteristics
- Mount Type
- Hanging Mount
- Form Factor
- Dome
- Durability
- Vandal Resistant
- Color Family
- White
- Product Color
- White
- Diameter
- 180 mm
- Weight (Approximate)
- 1.90 kg
- Environmental Conditions
- Minimum Operating Temperature
- -30°C
- Maximum Operating Temperature
- 55°C
- Maximum Operating Humidity
- 95%
- Miscellaneous
- Features
- Back Light Compensation (BLC)
- Wide Dynamic Range
- Digital Noise Reduction
- Privacy Masking
- Gain Control
- White Balance
- Motion Detection
- Day/Night
- Tamper Detection
- Audio Detection
- Indoor/Outdoor
- Outdoor
- Package Contents
- 2MP Camera with built-in 1TB Rugged SSD
- SSD 1TB
- Impact Protection Rating
- IK10
- Ingress Protection Rating
- IP66
- IP67
- IP6K9K
