- General Information
- Manufacturer
- Hanwha Group
- Manufacturer Website Address
- http://www.hanwha.com
- Brand Name
- Wisenet
- Product Series
- Q
- Product Type
- Network Camera
- Technical Information
- HD Recording
- Yes
- Night Vision
- Yes
- Night Vision Distance
- 20 m
- Night Vision Type
- Infrared
- Display & Graphics
- Image Sensor Type
- CMOS
- Colour Supported
- Colour
- Field of View
- H : 98.6(Wide) ~ 30.8(Tele), V : 52.3(Wide) ~ 17.3(Tele), D : 115.7(Wide) ~ 35.3(Tele)
- Effective Camera Resolution
- 4 Megapixel
- Video
- Video Formats
- H.265M
- H.265H
- H.264M
- H.264H
- MJPEG
- H.265
- H.264
- Maximum Video Resolution
- 2560 x 1440
- Maximum Frame Rate
- 30 fps
- Analog Video Signal Format
- CVBS
- Lens
- Lens Type
- Varifocal
- Minimum Focal Length
- 3.20 mm
- Maximum Focal Length
- 10 mm
- Lens Included
- Yes
- Minimum Aperture
- f/2.9
- Maximum Aperture
- f/1.6
- Optical Zoom
- 3.1x
- Exposure
- Shortest Shutter Speed
- 1/12000 Second
- Longest Shutter Speed
- 1/5 Second
- Network & Communication
- Connectivity Technology
- Wired
- Remote Management
- Yes
- Storage
- Storage Type
- Memory Card
- Interfaces/Ports
- Network (RJ-45)
- Yes
- Power Description
- Input Voltage
- 12 V DC
- Physical Characteristics
- Mount Type
- Box Mount
- Flush Mount
- Corner Mount
- Pipe Mount
- Parapet Mount
- Pendant Mount
- Wall Mount
- Pole Mount
- Hanging Mount
- Gooseneck
- Backbox Mount
- Form Factor
- Dome
- Color Family
- White
- Product Color
- White
- Diameter
- 119.8 mm
- Weight (Approximate)
- 320 g
- Environmental Conditions
- Minimum Operating Temperature
- -10°C
- Maximum Operating Temperature
- 55°C
- Maximum Operating Humidity
- 95%
- Miscellaneous
- Features
- Built-in IR LED
- Day/Night
- Built-in Mechanical ICR
- Wide Dynamic Range
- Motion Detection
- Tamper Detection
- SD Card Local Storage
- Back Light Compensation (BLC)
- Digital Noise Reduction
- Privacy Masking
- Auto Gain Control
- Automatic White Balance
- Alarm Triggering
- Built-in Microphone
- Audio Compression
- Indoor/Outdoor
- Indoor
