- General Information
- Manufacturer
- Kramer Electronics LTD
- Manufacturer Website Address
- http://www.kramerelectronics.com
- Brand Name
- Kramer
- Product Type
- Video Extender Receiver
The TP-580RXR is an extended range, HDBaseT twisted pair receiver for HDMI, bidirectional RS-232 and IR signals. The TP-580RXR receives an HDBaseT twisted pair signal from the TP-580TXR and converts it back into HDMI, RS-232 and IR signals.
- Technical Information
- Connectivity Technology
- Wired
- Number of Output Devices Supported
- 1
- Maximum Operating Distance
- 180 m
- Video
- Graphics Modes
- Full HD
- Maximum Video Resolution
- 1920 x 1080
- Interfaces/Ports
- Network (RJ-45)
- Yes
- HDMI Out
- Yes
- Serial Port
- Yes
- Number of Network (RJ-45) Ports
- 1
- Number of HDMI Outputs
- 1
- Media & Performance
- Media Type Supported
- Twisted Pair
- Twisted Pair Cable Standard
- Category 7
- Physical Characteristics
- Receiver Height
- 25.40 mm
- Receiver Width
- 119.38 mm
- Receiver Depth
- 76.20 mm
- Form Factor
- Rack-mountable
- Receiver Weight (Approximate)
- 635 g
