Lenovo ThinkSystem ST650 V2 7Z74A030EA 4U Tower Server - 1 x Intel Xeon Silver 4309Y 2.80 GHz - 32 GB RAM - 12Gb/s SAS, Serial ATA Controller

  • Part: 1094170
£1,902.00

Availability

In Stock

The Lenovo ThinkSystem ST650 V2 is an ideal 2-socket 4U tower server for small businesses up to large enterprises that need industry-leading reliability, management, and security, as well as maximizing performance and flexibility for future growth. The ST650 V2 is based on the 3rd generation Intel Xeon Scalable processor family and the Intel Optane Persistent Memory 200 Series.

The ST650 V2 is designed to handle a wide range of workloads, such as databases, virtualization and cloud computing, virtual desktop infrastructure (VDI), infrastructure security, systems management, enterprise applications, collaboration/email, streaming media, web, and HPC.

  • General Information
    • Manufacturer
    • Lenovo Group Limited
    • Manufacturer Website Address
    • http://www.lenovo.com/uk/en/
    • Brand Name
    • Lenovo
    • Product Line
    • ThinkSystem
    • Product Series
    • ST650 V2
    • Product Type
    • Server
  • Warranty
    • Limited Warranty
    • 3 Year
    • Additional Warranty Information
    • Three-year or one-year customer-replaceable unit and onsite limited warranty, 9 x 5 next business day. Optional service upgrades are available.

  • Processor
    • Number of Processors Supported
    • 2
    • Number of Processors Installed
    • 1
    • Processor Manufacturer
    • Intel
    • Processor Type
    • Xeon Silver
    • Processor Generation
    • 3rd Gen
    • Processor Model
    • 4309Y
    • Processor Core
    • Octa-core (8 Core)
    • Processor Speed
    • 2.80 GHz
    • Cache
    • 12 MB
  • Chipset
    • Chipset Manufacturer
    • Intel
    • Chipset Model
    • C621A
  • Memory
    • Standard Memory
    • 32 GB
    • Memory Technology
    • TruDDR4
    • Memory Clock Speed
    • 3.20 GHz
    • Error Checking
    • ECC
    • Total Number of Memory Slots
    • 32.0
    • Number of Occupied Memory Slots
    • 1
    • Intel Optane Memory Ready
    • Yes
    • Signal Processing
    • Registered (Buffered)
  • Controllers
    • Controller Type
    • 12Gb/s SAS
    • Serial ATA
    • Controller Model
    • 9350-8i
    • RAID Supported
    • Yes
  • I/O Expansions
    • Number of Total Expansion Bays
    • 10
    • Number of External 5.25" Bays
    • 2
    • Number of Internal 2.5" Bays
    • 8
    • Number of Media Drive Bays
    • 2
    • Number of SFF Bays
    • 8
    • Hot Swappable Bays
    • Yes
    • Total Number of Expansion Slots
    • 9.0
    • PCI Express x8 (Gen 3.x) Slots
    • 5
    • PCI Express x16 (Gen 3.x) Slots
    • 4
    • PCI Express Details
    • Up to nine PCIe slots, eight of which are PCIe 4.0 and are standard.
  • Display & Graphics
    • Graphics Controller Manufacturer
    • Matrox
    • Graphics Controller Model
    • G200
    • Graphics Memory Capacity
    • 16 MB
  • Network & Communication
    • Ethernet Technology
    • 10 Gigabit Ethernet
  • Interfaces/Ports
    • Total Number of USB Ports
    • 7
    • Number of USB 2.0 Ports
    • 1
    • Network (RJ-45)
    • Yes
    • Number of Network (RJ-45) Ports
    • 3
    • VGA
    • Yes
    • Number of VGA Ports
    • 1
    • Remote Management
    • Yes
    • Remote Management Controller
    • XClarity Controller (XCC) Enterprise
  • Operating System
    • Operating System Supported
    • Windows Server 2016
    • Windows Server 2019
    • Windows Server 2022
    • Red Hat Enterprise Linux 7.9
    • Red Hat Enterprise Linux 8.2
    • Red Hat Enterprise Linux 8.3
    • Red Hat Enterprise Linux 8.4
    • Red Hat Enterprise Linux 8.5
    • Red Hat Enterprise Linux 8.6
    • Red Hat Enterprise Linux 8.7
    • Red Hat Enterprise Linux 8.8
    • Red Hat Enterprise Linux 9.0
    • Red Hat Enterprise Linux 9.1
    • Red Hat Enterprise Linux 9.2
    • SUSE Linux Enterprise Server 12 SP5
    • SUSE Linux Enterprise Server 15 SP2
    • SUSE Linux Enterprise Server 15 SP3
    • SUSE Linux Enterprise Server 15 SP4
    • SUSE Linux Enterprise Server 15 SP5
    • Ubuntu 18.04 LTS
    • Ubuntu 22.04 LTS x64
  • Power Description
    • Input Voltage
    • 120 V AC
    • 230 V AC
    • Number of Power Supplies Supported
    • 2
    • Number of Power Supplies Installed
    • 1
    • Plug/Connector Type
    • C13/C14
    • Maximum Power Supply Wattage
    • 750 W
    • Hot Swappable Power Supply
    • Yes
    • Power Source
    • Power Supply
  • Physical Characteristics
    • Form Factor
    • Tower
    • Rack Height
    • 4U
    • Height
    • 462 mm
    • Width
    • 175 mm
    • Depth
    • 734 mm
    • Weight (Approximate)
    • 39.28 kg
  • Miscellaneous
    • Security Features
      • Administrator and Power-on Password
      • Trusted Platform Module (TPM)
      • Self-encrypting Drives with Support for IBM Security Key Lifecycle Manager
      • Lockable sSde Cover to Help Prevent Access to Internal Components
    • Energy Star
    • Yes
    • Environmentally Friendly
    • Yes
    • Energy Efficiency Certification
    • China Energy Conservation Program (CECP)
