The MC110CS is a media converter designed to convert 100BASE-FX fiber to 100Base-TX copper media or vice versa. Designed under IEEE 802.3u 10/100Base-TX and 100Base-FX standards, the MC110CS is designed for use with single-mode fiber cable utilizing the SC-Type connector.
- General Information
- Manufacturer
- TP-LINK Technologies Co., Ltd
- Manufacturer Website Address
- http://www.tp-link.com
- Brand Name
- TP-Link
- Product Type
- Transceiver/Media Converter
- Interfaces/Ports
- Total Number of Ports
- 2
- Network (RJ-45)
- Yes
- Number of Network (RJ-45) Ports
- 1
- Number of SC Ports
- 1
- Media & Performance
- Media Type Supported
- Twisted Pair
- Optical Fiber
- Fiber Mode Supported
- Single-mode
- Maximum Distance Supported
- 20 km
- Fiber Optic Cable Core/Cladding Specification
- 9/125 µm
- Network & Communication
- Ethernet Technology
- Fast Ethernet
- Network Technology
- 10/100Base-TX
- 100Base-FX
- Power Description
- Power Source
- AC Adapter
- Physical Characteristics
- Form Factor
- External
- Height
- 27.9 mm
- Width
- 94 mm
- Depth
- 73.7 mm
- Miscellaneous
- Additional Information
Wavelength: 1310 nm
