Omada's Software Defined Networking (SDN) platform integrates network devices, including access points, switches, and gateways, providing 100% centralized cloud management. Omada creates a highly scalable network all controlled from a single interface
- General Information
- Manufacturer
- TP-LINK Technologies Co., Ltd
- Manufacturer Website Address
- http://www.tp-link.com
- Brand Name
- TP-Link
- Product Line
- Omada
- Product Type
- Ethernet Switch
- Technical Information
- Features
- Zero-Touch Provisioning (ZTP)
- Energy Efficient
- Loop Protection
- Surge Protection
- DHCP Snooping
- Interfaces/Ports
- Total Number of Network Ports
- 24
- Network (RJ-45)
- Yes
- Port/Expansion Slot Details
- 24 x 1/2.5/5/10 Gigabit Ethernet PoE++ RJ-45 Network Port
- 8 x 1/10 Gigabit Ethernet SFP+ Expansion Slot
- 1 x RJ-45 Console Port
- 1 x USB Type C Console Port
- Media & Performance
- Media Type Supported
- Twisted Pair
- Optical Fiber
- Ethernet Technology
- Fast Ethernet
- Gigabit Ethernet
- 2.5 Gigabit Ethernet
- 5 Gigabit Ethernet
- 10 Gigabit Ethernet
- Network Technology
- 100/1000Base-T
- 2.5GBase-T
- 5GBase-T
- 10GBase-T
- 1000Base-X
- 10GBase-X
- Maximum Data Transfer Rate
- 1.25 GB/s
- I/O Expansions
- Total Number of Expansion Slots
- 8
- Expansion Slot Type
- SFP+
- Number of SFP+ Slots
- 8
- Network & Communication
- Layer Supported
- 2
- Networking Standards
- IEEE 802.1Q
- IEEE 802.1p
- IEEE 802.1x
- IEEE 802.3ah
- IEEE 802.1ab
- IEEE 802.3az
- IEEE 802.3u
- IEEE 802.3ab
- IEEE 802.3an
- IEEE 802.3z
- IEEE 802.3bz
- IEEE 802.3ae
- IEEE 802.3af
- IEEE 802.3at
- IEEE 802.3x
- IEEE 802.3bt
- IEEE 802.3ad
- IEEE 802.1D
- IEEE 802.1w
- IEEE 802.1s
- Management & Protocols
- Manageable
- Yes
- Reliability
- MTBF
- 315002 Hour
- Power Description
- PoE (RJ-45) Port
- Yes
- PoE Budget
- 770 W
- Input Voltage
- 120 V AC
- 230 V AC
- Frequency
- 50 Hz
- 60 Hz
- Power Source
- AC
- Power Supply
- PoE++
- Power Consumption
- 1010.20 W
- Physical Characteristics
- Product Material
- Metal
- Form Factor
- Rack-mountable
- Height
- 43.2 mm
- Width
- 439.4 mm
- Depth
- 330.2 mm
- Miscellaneous
- Application/Usage
- Network
- Wireless Access Point
- Certifications & Standards
- CE
- FCC
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
